The KHP-VH100 hazardous chemical loading and unloading safety monitoring device meets the specifications of GB/T 19056-2012 Vehicle Driving Recorder and AQ3004-2005 Hazardous Chemical Vehicle Transport Safety Monitoring Vehicle Terminal. The key consideration is the entry of hazardous chemical transport vehicles from ordinary atmospheric environments into explosive environments (Zone 1), and before the loading and unloading operations begin, the hazardous chemical transport vehicles and all non explosion proof equipment carried must be in a parking/shutdown state. The monitoring equipment actually does not play a role in monitoring the loading and unloading process. So this product adopts explosion-proof design to meet seamless safety monitoring throughout the entire loading and unloading process.

This product is installed on hazardous chemical transportation vehicles and uses high-precision Beidou technology to supervise the entire process of loading, unloading, and transportation of hazardous chemicals. The driver and escort are identified using facial recognition and identity verification technology to prevent unauthorized operations such as changing people on the way and fatigue driving. It is also equipped with voice intercom and video monitoring modules for abnormal alarm information reminders.

The terminal seamlessly connects with the backend business system, allowing drivers and escorts to easily obtain transportation tasks, update transportation status, and push messages with just one click.

The KHP-VH100 hazardous chemical loading and unloading transportation monitoring device consists of an explosion-proof vehicle terminal, an explosion-proof eID interaction system, and several explosion-proof audio and video peripherals. The explosion-proof vehicle terminal adopts a new generation of audio and video dedicated high-speed processor and embedded operating system, combined with H.264 video compression, Beidou satellite positioning and other technologies, to record audio and video recordings and driving information data, and upload them to the company or relevant management departments through 4G wireless data. The explosion-proof vehicle terminal provides detailed encrypted driving data, ensuring the effectiveness and security of the data, making it easier for management personnel to accurately manage vehicles and drivers, effectively scheduling and preventing in advance, greatly improving work efficiency and quality.

Product Features

Built in high-sensitivity Beidou and GPS dual-mode positioning module.

Supports 4-channel high-definition CVBS or AHD camera access, with full channel support for 720P encoding.

Built in 1 2.5-inch 1TB hard drive.

Built in 1 16GB SD/SDHC card, capable of supporting up to 128GB per card.

Support viewing of driving information, vehicle information, timeout driving records, driver information, alarm status, positioning status, video recording status, etc.

Supports multiple alarms, including video loss alarm and manual trigger alarm.

Built in G-sensor, capable of collision and rollover alarm functions.

Support real-time audio and video synchronization transmission function;

Support remote playback of local video recording function;

Positioning antenna disconnection and short circuit alarm function

Support integration with the platform to receive and broadcast information issued by the platform, as well as TTS text to speech broadcasting function.

Central voice monitoring and voice intercom function.

Equipped with power-off protection function, it can also ensure the integrity of critical data in case of sudden power outage.

Rich expansion interfaces, supporting external device access such as RS232 serial port, RS485, CAN, etc.

application area

Full process supervision of hazardous chemical transportation vehicles
